Max! Max! Max!
Maximum innovation, maximum performance, maximum fun!
Max SLR bumps is the new 120mm MTB of Travel which was born with L’Intent to give the Factory Team athletes Wilier Pirelli a modern and versatile race bicycle: performing suspensive system, specifies to the guide, safe.
A bicycle that from the first pedaling will make you feel on an ideal means to compete and have fun on the most demanding paths.
Specific
Chassis: Impact Max Slr – Carbon Monocoque Frame Hus Mod + High Impact Carbon Weave
Fork: Fox 34 Step-Cast Kashima 120 mm
Rear shock absorber: Fox Float Sl Factory Kashima, Evol Lp + Remote Up 190×45 mm
Handlebar: Impact Max bar integrated carbon stem and bar -27 °
Handlebar weight: 285 g +/- 5%
Steering series: Across Headset AIF610
Group: SRAM GX EAGLE AXS T-Type 1x12s
Gearbox leve: Sram axs pod right discrete clamp
Brakes: Shimano Deore BL-M8100 + Br-M8100
Rotor: Shimano RT-MT800 180 /160 cl
Change: SRAM GX EAGLE AXS T-TYPE GS-GX-E-D1
Char: SRAM GX Eagle Axs T-Type FC-GX-D1 32T
Central movement: Sram dub press fit bb-dub-pf-a1 92 mm mtb
Cassette: SRAM GX EAGLE T-TYPE CS-XS-1275-A1 10-52T
Chain: RAM GX Eagle T-Type Flattop CN-TTYP-GX-A1
Wheels: Miche K6 Carbon 29 ”TLR
Covers: Vittoria Mezcal XC-Trail 29 ”X2.35 TLR
Saddle: Selle San Marco Shortfit Startup
Bra: Switch Sw 100 Travel Dropper ⌀ 31.6 mm
Pin: Rear 12×178.5mm p1.0
Chassis weight: 1730 g +/- 5% (Rear Shox Not Included)
Geometries
| S | M | L | XL | |
|---|---|---|---|---|
| L (cm) | 57.5 | 60.3 | 63.2 | 66.4 |
| H (cm) | 41 | 44 | 48 | 52 |
| A (°) | 75 | 75 | 75 | 75 |
| L1 (cm) | 43.5 | 43.5 | 43.5 | 43.5 |
| H1 (cm) | 8.8 | 8.8 | 9.2 | 10.4 |
| A1 (°) | 67.5 | 67.5 | 67.5 | 67.5 |
| Reach (mm) | 415 | 443 | 471 | 500 |
| Stack (mm) | 598 | 598 | 602 | 613 |
| Wheelbase (mm) | 1126 | 1154 | 1184 | 1218 |
| Wheelset (”) | 29” | 29” | 29” | 29” |
| Travel (mm) | 120 | 120 | 120 | 120 |
